Bitusheet XL Membrane
Flexible Membrane
Key Features
- Cold applied flexible membrane
- Tanking membrane for underground structures
- Easy to fix
- Effective barrier to transmission of water
- Self bonding rubber bitumen compound
- Siliconised release paper on one side
- Resists Radon and Carbon Dioxide gases
- BBA Certified 94/3048
What is Bitusheet XL Membrane?
BITUSHEET XL Waterproofing Membrane consists of a self-bonding rubber bitumen compound, which is covered on one side with a tough multi-ply, cross laminated polyethylene sheet and protected on the other side by a siliconised release paper. The release paper is removed prior to installation onto a primed concrete surface.
Resistant to contaminated ground water, aggressive soils and dilute acids and alkalis. BITUSHEET XL Membrane provides resistance to the passage of Radon and Carbon Dioxide gases better than the standard membrane requirements in BRE Reports 211 and 212.
Technical Data
|
Physical Properties
|
Value
|
Test Method
|
|
Membrane strength
|
50n/cm
|
BS2782 method 2
|
|
% Elongation of membrane
|
600%
|
D638
|
|
Water penetration at Joint
|
0%
|
MOAT 5.1.4
|
|
Compound elongation
|
1250%
|
BS2782
|
|
Puncture resistance
|
230N
|
ASTM E154
|
|
Adhesion [1800 peel]
|
4N/mm
|
|
|
Water Vapour transmission
|
0.3g/m2/24h
|
|
|
Elongation at break
|
300%
|
|
|
Resistance to impact [mm]
|
> 500
|
|
|
Resistance to static loading Kg
|
> 20
|
|
